### An introduction to fast, ordered message retention in Selium.

Message retention has finally landed for Selium, thanks to Selium Log!

Selium Log lays the foundation for complex streaming use-cases, while crossing off another huge milestone for Selium, with many more to come in the following months.

I'm excited to introduce Selium Log and give you all a brief look into our architecture without getting overly technical, so let's get started!

## Justification

Previously, Selium was limited to temporary, in-memory message queuing. As
messages were produced, they would be destroyed after attempted delivery. While
this certainly afforded considerable amounts of throughput, the
destructive, forgetful nature of the in-memory queue meant that the scope of
applications using Selium was severly limited. We set out to address the
following shortcomings of our current implementation.

### Message Retention

The previous message broker did not persist any messages to either the filesystem or an
in-memory cache, and would rather retain a buffer containing the current message to deliver. The
message would then be popped from the buffer before attempting delivery to all connected
subscribers, and the broker would forget all about it. This is more than fine, if not ideal
for use-cases that require high throughput while allowing for the occasional missed delivery,
but is a show-stopper for complex applications that need to retain a history of all produced messages.

### Message Replay

Previously, subscribers were only privy to messages produced
following their subscription to the topic. Once messages were popped
from the queue to attempt delivery, they were destroyed. This made
Selium unsuitable for any applications requiring playback of older
messages, such as chat, financial and logging applications, to name
a few examples.

### Message Ordering

Message Ordering is a crucial feature for many critical event-based
applications. For example, medical and financial applications would certainly
like to be notified of events in the order that they arrive, in order to accurately monitor patient
insulin levels, or prevent inaccurate financial forecasts, respectively.

## Enter Selium Log

With the introduction of Selium Log, we believe that many of our previous broker implementation's shortcomings have either been addressed, or can now easily be addressed in future updates.

### Message Retention

Selium Log allows retention of produced messages based on a retention policy provided by the Selium Client user,or Selium Log library author. Messages are persisted in the filesystem until they are deemed stale, before they are cleaned up by an asynchronous background task. In the following code, message retention is configured while establishing a producer stream:

Let's say we want to retain log segments for up to seven days. Note that this is the default retention period!

```rust
let publisher = connection
    .publisher("/acmeco/stocks")
    .with_encoder(StocksEncoder)
    .retain(chrono::Duration::from_days(7))?
    .open()
    .await?;
```

The retain method will accept any value that can be fallibly converted into a u64, so we're not limited to chrono! For example, let's express the same retention period, but with the standard library's `Duration` type.

```rust
let publisher = connection
    .publisher("/acmeco/stocks")
    .with_encoder(StocksEncoder)
    .retain(std::time::Duration::from_secs(60 * 60 * 24 * 7))?
    .open()
    .await?;
```

How about just passing the retention period directly as a u64?

```rust
const SEVEN_DAYS_IN_SECONDS: u64 = 60 * 60 * 24 * 7;

let publisher = connection
    .publisher("/acmeco/stocks")
    .with_encoder(StocksEncoder)
    .retain(SEVEN_DAYS_IN_SECONDS)?
    .open()
    .await?;
```

### Message Replay

Selium Log solves this shortcoming by allowing subscribers in client
code to optionally specify a log offset to start reading messages from. This is
accomplished with the `Offset` type while establishing a subscriber stream.
In the following example code, there are a few different examples of usage.

Let's begin consuming from the very beginning of the log. We don't want to
miss a thing!

```rust
let subscriber = connection
    .subscriber("/acmeco/stocks")
    .with_decoder(StocksDecoder)
    .seek(Offset::FromStart(0))
    .open()
    .await?;
```

Now we'll start reading from 1,000 messages from the end of the log.

```rust
let subscriber = connection
    .subscriber("/acmeco/stocks")
    .with_decoder(StocksDecoder)
    .seek(Offset::FromEnd(1000))
    .open()
    .await?;
```

What if we don't care about the historical events in the log, and just want
to catch new messages as they come in? It should be noted that this is
the default behaviour if no seek offset is provided!

```rust
let subscriber = connection
    .subscriber("/acmeco/stocks")
    .with_decoder(StocksDecoder)
    .seek(Offset::FromEnd(0))
    .open()
    .await?;
```

Currently, messages can only be replayed by providing a numeric offset, but a future update will introduce replaying messages from a specific timestamp. The proposed API to start replaying messages from 7 days ago may look like the following:

```rust
let subscriber = connection
    .subscriber("/acmeco/stocks")
    .with_decoder(StocksDecoder)
    .seek(Offset::FromTimestamp(Duration::from_days(7)))
    .open()
    .await?;
```

### Message Ordering

The previous broker implementation does feature message ordering, but it comes
with an added runtime cost that is hard to ignore. With Selium Log, due to the
sequential, atomic nature of the log, message ordering is inherent to the design,
and is thus provided free of charge!

### Delivery Guarantees

An important feature of any message queue is strong delivery guarantees. While full support for the different tiers of guarantees is still on the horizon, Selium Log lays down the foundation to allow publishers to easily apply backpressure when the most strict guarantees are required, and facilite simple retries upon failed delivery to subscribers.

## Architecture

Developers possessing a background with Apache Kafka will find the Selium Log architecture to be quite familiar! In the following sections, I'll attempt to describe each component of the log.

### Segment

Our logging implementation is represented by one or more segments, with each segment comprised of a memory-mapped index file, serving as a lookup for the segment's records, and an append-only data file containing said records.

Only the most current segment can be designated as the mutable, "hot" segment, while older segments are read-only, and are retained until their eventual cleanup. Likewise, once the current hot segment exceeds a defined threshold, it will also be marked as read-only, while a new segment is created and assigned as the hot segment in its place.

When a segment is created, two files will be created in the directory pertaining to that log, which will represent the index and data files respectively. The files will use the naming convention of `<base-offset>.index` and `<base-offset>.data`, respectively (I'll explain exactly
what the base-offset is soon enough!). When a log is newly created, the initial hot segment will always be created, so a fresh log directory for the `acmeco/stocks` topic should look like the following:

![file tree](/images/news/introducing-selium-log/tree1.svg)

Segments will eventually become full, depending on the configured `LogConfig::max_index_entries` setting, so new segments will be created to keep write buffers at reasonable sizes, allow efficient seeking, and reduce overhead when synchronizing the memory-mapped index with the filesystem.

For example, for a log with segments no larger than 10,000 entries, the log directory may look like the following, depending on the maturity of the log:

![file tree](/images/news/introducing-selium-log/tree2.svg)

#### Stale Segments

Nothing can last forever. The same can be said for log segments. It's all well and good to spawn segment after segment as new messages are commited to the log, and continue chugging along, but eventually, storage costs will increase, and ultimately, the filesystem will be overwhelmed.

To alleviate this issue, a retention period can be specified for log segments, to prevent logs from growing too large and/or retaining stale data. When logs are created or resumed, a background task is spawned, which asynchronously scans for stale log segments and removes them from the filesystem. A segment is considered stale when the last modified timestamp in the metadata of the data file falls behind the specified retention period.

As an example, let's consider a retention policy of 7 days. As of writing this article, it is currently __3PM AEST__ on __01/05/2024__, so the UNIX timestamp for 7 days ago is __1713934800__. The following table displays each segment in a log along with their last modified time. Each segment is marked stale if its _Last Modified Timestamp_ is less than __1713934800__, which is true for offsets __0__, __10000__, and __20000__.

![stale segments](/images/news/introducing-selium-log/stale.svg)

#### Flushing

Replication has not yet been implemented for Selium Log as of this release, but is a planned feature.

Due to this shortcoming, durability can be tough to achieve alongside high throughput on a single
node. Most of the latency comes from the I/O overhead of flushing the memory-mapped
index and data files to the filesystem.

To compensate for this overhead, the flushing frequency can be tweaked via the
`FlushPolicy` struct, to strike a balance between durability and throughput. Through
constructing a `FlushPolicy`, users can determine the flushing interval, and optionally,
a write-count threshold to trigger flushing.

Tweaking these settings can greatly increase throughput, but since messages aren't
delivered until they're successfully flushed, it comes at the cost of possibly losing a
certain amount of messages. For example, if the flushing interval is 5 minutes, it's
possible to lose up to 5 minutes of messages upon an unexpected critical failure, as the
write-buffer will not be flushed to the filesystem. Use `FlushPolicy::every_write` if
durability is a critical concern.

### Index

The index is a memory-mapped file that serves as a lookup directory of all messages in the segment, describing where any messages in the log can be located via byte offset. Given a relative offset, a fast lookup of a byte offset in the data file can be performed via a binary search. The index is comprised of one or more entries that are each 20 bytes in length, with the following structure:

![index fields](/images/news/introducing-selium-log/index_fields.svg)

#### A note on offsets

I've mentioned base offsets and relative offsets quite a bit now, so what are they, really? Every segment starts from a base offset, starting from offset 0, with each entry in the index having its own offset relative to that base offset, beginning from 1.

When an index is full, a new segment will be created using the next offset as the new base offset. A stripped down, visual representation of these offsets would look like the following:

![index](/images/news/introducing-selium-log/index.svg)

As you can see, regardless of the base index for the segment, the relative offset for the index will always start from 1, as it is relative to that segment. This makes lookups trivial, as you can easily locate an index via a comparison with the base offset, and then subtract the difference to determine the relative offset.

Using the example above, to locate a message with an offset of __10,301__, the log implementation
would perform the following comparisons against the index base offsets:

1. Is _10,301_ smaller than _20,000_? **Yes!** This is also not the index we're after.
2. Is _10,301_ smaller than _10,000_? **Nope!** This is the index to consult!

The relative offset is then calculated using the following formula:

```latex
offset - base = relative
```

The above example would determine the relative offset as follows:

```latex
10,301 - 10,000 = 301
```

We can then ask `10000.index` to fetch the byte offset for the entry with a relative offset of __301__. We now learn that the message is located at byte offset __9,632__ in `10000.data`!

![data](/images/news/introducing-selium-log/data.svg)

### Data File

The data file is quite simple: the messages are encoded into bytes before being stored sequentially in this file. The data file is seldom accessed without first consulting the index file for an initial byte offset.

#### Message Format

The message frame contains information required to parse the message, a calculated CRC used to verify message integrity, and the encoded records.

![message fields](/images/news/introducing-selium-log/message_fields.svg)

## Don't Need Retention?

If after reading all of the above, you've decided that log-based messaging isn't important for your use-case with Selium, fear not!

Selium Log won't be the only messaging style available in Selium, as we are working towards improving our previous high-throughput, forgetful message solution, so we can offer it as a secondary messaging style for publishers who wish to opt-out of retention.

## Open Source

Because we love open-source at Selium, our `selium-log` crate is entirely open source, so If you have an application that could make use of a lightweight, competent log-based message queue, then please feel free! No Selium dependency required!

Simply add the `selium-log` dependency to `Cargo.toml`, and you're good to go. An example of usage is as follows:

```rust
use anyhow::Result;
use selium_log::{config::LogConfig, message::Message, MessageLog};
use std::sync::Arc;

const MESSAGE_VERSION: u32 = 1;

#[tokio::main]
async fn main() -> Result<()> {
    let config = LogConfig::from_path("path/to/segments/dir");
    let log = MessageLog::open(Arc::new(config)).await?;
    let message = Message::single(b"Hello, world!", MESSAGE_VERSION);

    log.write(message).await?;
    log.flush().await?;
    let slice = log.read_slice(0, None).await?;

    if let Some(mut iter) = slice.messages() {
        let next = iter.next().await?;
        println!("{next:?}")
    }

    Ok(())
}

```

For extended usage, you can dig into the `selium-log` documentation. Contributions are always welcome, so feel free to open a PR in [our repository](https://github.com/seliumlabs/selium).

## Some Final Words

In closing, we're very excited to see what you build with Selium and Selium Log. We still have **awesome** things cooking, which we can't wait to share, so until then, thanks for tuning in, and **watch this space**!


Introducing Selium Log


Selium is a composable data streaming platform, written in Rust. If you're thinking that this all sounds pretty familiar, it is! Selium isn't pretending to have the first word on data and how to move it around, though hopefully this article will demonstrate some method to our madness.

## What else is there to say?

I don't like configuration. More accurately, I hate it. Especially the kind of “powerful” config that allows you to do things like overloading YAML with conditional statements, loops, variables and such. It's a pain to read, it's worse to write and it's unbearable to maintain. This opinion made me an awful DevOps engineer, but inspired me to start building Selium. Since then we've grown to a team of 3, but we are all in screaming agreement about one thing - everything in Selium must be configurable in code at runtime.

So what does Selium add to the conversation? In a word - simplicity. We aren't striving to do anything revolutionary with our platform, because the industry is already quite feature complete. Instead we're focussing on making Selium the most developer friendly streaming platform out there. We are still building towards feature parity with the _Kafkas_ and _RedPandas_ of the world, but with an unwavering focus on developer ergonomics.

### For example:

* **We don't have any configuration files.** We will probably introduce support for JSON/YAML to appease our operator friends, though they will never be mandatory, nor necessary.
* **We don't have any CLI for configuring Selium.** We don't need one. Selium's server configures itself when your code runs, so there's nothing to pre-configure. You're free to declare new topics/pipes with liberal abandon!
* **We are functional and declarative.** Coding in Selium should be a pleasant and predictable experience.
* **We are totally futures-compatible.** Producers are Sinks and consumers are Streams. Familiar already, huh?
* **We built our I/O around QUIC.** [QUIC](https://quicwg.org) is a really awesome reliable UDP protocol and allows us to do fun things like stream multiplexing and implicit mutual TLS.

## What does it look like?

Here's a complete example publisher:

```rust
use futures::SinkExt;
use selium::{prelude::*, std::codecs::StringCodec};

#[tokio::main]
async fn main() -> Result&lt;(), Box&lt;dyn std::error::Error&gt;&gt; {
    // Connect to Selium
    let connection = selium::custom()
        .endpoint("127.0.0.1:7001")
        .with_certificate_authority("certs/ca.der")?
        .with_cert_and_key("certs/me.der", "certs/me.key.der")?
        .connect()
        .await?;

    // Establish a new publisher `Sink` that publishes to the topic "/acmeco/stocks".
    let mut publisher = connection
        .publisher("/acmeco/stocks")
        .with_encoder(StringCodec)
        .open()
        .await?;

    // Now we have a Sink to do stuff with
    publisher.send("Hello, Selium!".to_owned()).await?;

    Ok(())
}
```

The only gotcha here is that you need to share your server's certificate authority with your clients, and client public keys with the server. Or, you can sign up for Selium Cloud for freeee. Then you won't need to share shit! Boom.

## Where does the road lead?

Ah mate, we have so much more planned! I can't wait to share with you what's coming in the medium term, but for now let's look at the immediate term:

* Message retention & replay
* Delivery guarantees
* Broader protocol support
* Improved docs and examples

What would you like to see? Maybe a new language binding? [Let us know](mailto:hello@selium.com?subject=Feature%20please&body=Hello%20Selium%2C%0A%0AI%20would%20like%20you%20to%20build%20this%3A%20%3CA%20pig%20that%20can't%20fly%20but%20looks%20so%20cool%3E.%0A%0ATa) what floats your boat.

If you like what we're doing, we would really appreciate your support! You can check out our GitHub here: [github.com/seliumlabs/selium](https://github.com/seliumlabs/selium).

Until next time, have a fabulous this time!
